Multi-Function Magnetron Sputtering Metallizer Used For Coating PET Film
Product Description
Magnetron sputtering is composed of a vacuum system, a winding system, a magnetron target sputtering system, a control system, etc., and can achieve copper, lead, aluminum, tin, silver, etc. sputtering on thin films with a thickness of 2 μm to 300 μm. Can be accurately coated on the surface of various coils such as film, cloth, sponge, copper foil, paper, etc.
Magnetron sputtering can be said to be one of the great achievements in coating technology. It has the advantages of high sputtering rate, low substrate temperature rise, good film substrate bonding force, stable performance, convenient operation and control, etc. It uses physical vapor deposition to achieve sputtering and ion plating (hollow cathode ion plating, hot cathode ion plating, arc ion plating, reactive ion plating, radio frequency ion plating, and DC discharge ion plating).
The working principle of magnetron sputtering is that electrons collide with argon atoms in the process of flying to the substrate under the action of the electric field e, generating ar positive ions and new electrons; new electrons fly to the substrate, and the ar positive ions are under the action of the electric field Accelerate to fly to the cathode target. Bombing the target surface causes the target to sputter. In the sputtered particles, neutral target atoms or molecules are deposited on the substrate to form a thin film. The secondary electrons generated are affected by the electric and magnetic fields, resulting in a direction shift of e (electric field) × b (magnetic field), referred to as exb drift. Its motion trajectory is similar to a cycloid.
The magnetron winding series coating equipment is mainly used in higher-grade packaging, decoration, touch screen, field-effect lighting, radiation protection, heat insulation and frost prevention. The characteristics of the equipment are that the base material is neatly rolled, no scratches, high target utilization, uniform gas discharge from the inflation system, reasonable structure, stable performance, and convenient operation. ITO film, capacitor film, etc. can be plated with the magnetron winding series coating equipment. With the continuous development of coating technology, it will be more commonly used in other fields.
Technical Data
| Substrate | PET,PI,Metal foils.etc. |
| Substrate width | 1000mm-1600mm |
| Substrate thcickness | 12μm-200μm |
| Roll diameter | max. 800 mm |
| Speed | 0.5m/min-25m/min |
Features
1. Designed for the clean workshop
2.Hardly to produce dirty spots
3.High precision winding system
4. Modular design: convenient for users to maintain the machine
5. It can be sputtered on double sides at the same time to improve the working efficiency
Packaging & Delivery
1. Prompt delivery;
2. Professional logistic agent;
3. Well-trained and disciplined packing team;
4. After-sale service: Any questions or problems after receiving the product, please feel free to contact us. Problems would be solved for you immediately.
Competitive Advantages
1. We offer high quality products at competitive price;
2. customs clearance is guaranteed;
3. Good after-sale service;
4. Flexible payment terms;
5. With excellent products and efficient services, we are well known both at home and abroad.
Our Factory
Our customers
FAQ
Q: Is Dongsheng a factory or trading company?
A: Dongsheng is a factory.
Q:Where is your factory located? Can I visit it before I place an order?
A:Our factory is located in Hefei, Anhui,China; Welcome to visit our factory.
Q: How about the warranty and after-sale service?
A: We provide 12 months warranty and lifetime technic suport for all machinery. We have professional after-sale technical team, we can solve problems in time.
